DuVoice NANO - DL30N
Identifications
| Part number | DV-NANO |
| Technical part number | COMP-DL30N |
| Production start | May 2024 |
| Production end |
Specifications
| Processor | Intel N100 3.4Ghz Quad Core CPU |
| Memory | 16GB DDR5 |
| Integrated Graphics | Intel UHD Graphics |
| Hard Drive | 500GB or Larger NVMe SSD* |
| Audio | Realtek ALC888S |
| Dimensions | 1.7“H x 6.5”W x 7.5“ L |
| Power Supply | 19V 3.42A Power Adapter |
| LAN | Dual Intel I226-LM 2.5Gb/s |
| Slots | M.2 2280 Type M key socket, M.2 2230 Type A,E Key socket |
| USB | 8x USB 3.2 Gen 1 Ports |
| Onboard Video | Displayport, HDMI & VGA Video Connectors |
| Onboard Serial | 2 x RS232 |
| Onboard SATA | 1 SATA III Connector |
| Operating System | Windows 11 Enterprise |
| Operating Temperature | 0c-40c Maximum Ambient Temperature (Standing Configuration) |
| Safety Certifications* | CB, BSMI, cTUVus |
| EMI Certifications* | Fanless Solid State Design (No moving parts), VESA mount |
| Accessories | Vertical Orientation Stands, VESA Mount Plates, Power Adapter |
| Accessory Note | Keyboard, Mouse, and Monitor NOT included |
| Manufacturer | Shuttle Inc. |
| Warranty | 1 Yr Included, Extended Warranty Plans Available |
| Notes | Unformatted Size, Formatted Size Will Be Less. Certifications Provided By The Manufacturer. |
